M8 A-Code Female Connector – W8FA

M8 A-Code Female Connector – W8FA

SKU: W8FA Categories: ,

M8 A-Code Female Connector M8 A-Code Female Connector

Application & Features

Factory Automation
Communications
Medical Electronics
Transportation
Industrial Equipment & Tools
Commercial

Specifications

Insulator: Thermosetting Polymer
Contact Material: Brass
Shell Material: Brass
Contact Underplate: Nickel 50u” Min
Contact Area: 1u” Gold
Voltage Rating: 50V
Current Rating: 3 Amps
Contact Resistance: 0.5 ohms max.
Insulator Resistance: 100 Megohms min @ 500 VDC
Operating Temperature: -25° ~ +85° C
Protection Certification: IP67 (IEC60529)

Options

Green Options: RoHS(Bright Plated)
Contact Plating: Gold
Solder Tails: Gold
Solder Type: Through Hole (TH)
Shell Plating: Nickel
Coding: A-Code
Packaging: In Bag

Technical Sheets

Download PDF
Download CAD
